Brew opened the menu admin panel and realised the categories had long since become a tree: "Drinks" splits into "Coffee" and "Tea", "Coffee" splits into "Espresso drinks" and "Filter", and "Espresso drinks" is already "Cappuccino" and "Latte". In the table this is a single parent_id column pointing back at its own id. Marketing asked to export the menu "the way it looks on the board" — indented by nesting level, with the full path from the root — to drop into a banner. A plain JOIN is helpless here: nobody knows the depth of the tree in advance, and writing eight self-joins "just in case" is not an engineering solution.

An hour later a second incident landed. The logistics lead built a "where to ship the batch next" graph: from the warehouse to the workshop, from the workshop to the café. Someone mistakenly entered a row saying the leftovers ship from the café back to the warehouse. That closed a ring, Warehouse → Workshop → Café → Warehouse, and the very first naive recursive query over this graph hung: it walked in circles forever until the server hit a limit. Both incidents are about the same construct — the recursive CTE we promised back in 04-06, when we first started talking about trees in the relational model. Time to deliver it.

Why this unit is on psql, not sqlc

The whole course keeps sqlc in the leading role by default. But here we deliberately drop the tool, because the lesson is exactly about a feature sqlc cannot read. Cycle protection in the SQL standard is expressed by the CYCLE clause: it appends to the recursion result two "virtual" columns, is_cycle and path, that exist in no table of the schema. sqlc v1.30.0 analyses the query statically, against the DDL, fails to find those columns, and crashes with column "is_cycle" does not exist. Reshaping the lesson to fit the tool would mean throwing out the lesson's core. So we pick the feature over the tool and drive the demo with a plain psql script, demo.sql. It is the same escape-hatch logic as in 02-05 and 03-05: when a construct runs into the limits of the static analyser, the construct wins.

WITH RECURSIVE: anchor plus step

A recursive CTE always consists of two parts glued together by UNION ALL. The first is the anchor: the starting rows the traversal begins from. For a tree these are the roots — categories with no parent (parent_id IS NULL). The second is the recursive step: it takes the rows already found and attaches their children. Postgres repeats the step again and again until it stops adding new rows — on a tree this naturally happens once the traversal reaches the leaves.

What matters is that at each level we don't merely descend, we accumulate context. In the anchor we set depth = 1 and a path consisting of the single current node; in the step we add one to depth and append the current node to the parent's path. This way every row carries both its depth and the entire road from the root down to it — exactly what marketing asked for.

Here is the whole tree — those same parent_ids laid out by level. The traversal runs top to bottom in exactly this order (pre-order: a parent, then its whole subtree, then the sibling):

depth 1   Drinks
depth 2   ├─ Coffee
depth 3   │  ├─ Espresso drinks
depth 4   │  │  ├─ Cappuccino
depth 4   │  │  └─ Latte
depth 3   │  └─ Filter
depth 2   └─ Tea
depth 3      └─ Green

The anchor is the root Drinks (no parent); each recursive step descends one level, to the children of already found nodes. idpath — an array of ids along the branch — sets this pre-order in the output.

What our code shows

The first part of demo.sql traverses the category tree. The anchor selects the roots and initialises three accumulators: depth, an array of identifiers idpath, and a string path namepath. The recursive step joins the table to itself on c.parent_id = t.id and continues all three accumulators:

WITH RECURSIVE tree AS (
    -- якорь: корни (нет родителя), глубина 1, путь = [свой id]
    SELECT id, parent_id, name, 1 AS depth,
           ARRAY[id]   AS idpath,
           name::text  AS namepath
    FROM category_tree_lab
    WHERE parent_id IS NULL
    UNION ALL
    -- рекурсивный шаг: дети уже найденных узлов, глубина +1, путь дополняем
    SELECT c.id, c.parent_id, c.name, t.depth + 1,
           t.idpath   || c.id,
           t.namepath || ' > ' || c.name
    FROM category_tree_lab c
    JOIN tree t ON c.parent_id = t.id
)
SELECT depth,
       repeat('  ', depth - 1) || name AS category,
       namepath                        AS path
FROM tree
ORDER BY idpath;   -- массив id → детерминированный pre-order, без зависимости от collation

The ORDER BY idpath deserves a separate word. A recursive CTE itself promises nothing about row order — without an explicit sort the output could shuffle from run to run. We want the familiar pre-order: a parent, then its whole subtree, then the next sibling. It is tempting to sort by namepath — the string path with names — but then the order of "Coffee" and "Tea" would start depending on the database collation: in one locale Cyrillic sorts one way, in another differently, and the output drifts. So we sort by idpath — an array of numeric ids. Arrays in Postgres compare element by element, number against number, untouched by any collation. The result is a stable, reproducible traversal on any installation.

The second part is the same machinery aimed at a cyclic route graph. Here we care not about the path but about the very fact of looping, and that is caught by the SQL-standard CYCLE clause (Postgres has understood it since version 14):

WITH RECURSIVE walk AS (
    SELECT id, next_id, name, 1 AS step
    FROM cyclic_routes_lab
    WHERE id = 1
    UNION ALL
    SELECT r.id, r.next_id, r.name, w.step + 1
    FROM cyclic_routes_lab r
    JOIN walk w ON r.id = w.next_id
) CYCLE id SET is_cycle USING path   -- помечаем повтор id и кладём пройденный путь в path
SELECT step, id, name, is_cycle, path
FROM walk
ORDER BY step;

It reads like this: "watch for a repeat of the id value; as soon as the recursion comes back to an already visited id, set the is_cycle flag to true and keep in path the list of all visited nodes". Postgres materialises the is_cycle and path columns itself — they are not in cyclic_routes_lab, and it is precisely their absence from the schema that trips sqlc. The key part is the behaviour on a repeat: having found the node already in path, Postgres marks the row and does not take the next recursive step from it. The ring is broken, the recursion ends on its own.

Running it

docker compose up -d
make lecture L=08-analytical-and-lateral/08-04-recursive-ctes

T=run is the default target: it runs demo.sql through psql. From inside the unit directory, make run is enough. The output is deterministic — it repeats verbatim on every run.

(The demo prints in Russian.)

1) Обход дерева категорий сверху вниз (WITH RECURSIVE):
 depth |       category       |                     path
-------+----------------------+----------------------------------------------
     1 | Напитки              | Напитки
     2 |   Кофе               | Напитки > Кофе
     3 |     Эспрессо-напитки | Напитки > Кофе > Эспрессо-напитки
     4 |       Капучино       | Напитки > Кофе > Эспрессо-напитки > Капучино
     4 |       Латте          | Напитки > Кофе > Эспрессо-напитки > Латте
     3 |     Фильтр           | Напитки > Кофе > Фильтр
     2 |   Чай                | Напитки > Чай
     3 |     Зелёный          | Напитки > Чай > Зелёный


2) Тот же обход по зациклённому графу, но с CYCLE — рекурсия сама тормозит:
 step | id | name  | is_cycle |       path
------+----+-------+----------+-------------------
    1 |  1 | Склад | f        | {(1)}
    2 |  2 | Цех   | f        | {(1),(2)}
    3 |  3 | Кафе  | f        | {(1),(2),(3)}
    4 |  1 | Склад | t        | {(1),(2),(3),(1)}

In the first block the indentation repeat(' ', depth - 1) draws the tree, and path shows the full road from the root — exactly what goes into the banner. In the second, the traversal walked Warehouse → Workshop → Café and on the fourth step came back to id = 1. Postgres saw that id in the accumulated path, set is_cycle = t, and put the closed ring {(1),(2),(3),(1)} into path. On that row the traversal stops — instead of circling through warehouse, workshop and café forever.

The fence

• Without an explicit guard, recursion over a cyclic graph never terminates — and that is not a theoretical risk but the very hung query from the incident. Before Postgres 14 there was no CYCLE clause, and cycles were caught by hand: you carried an array of visited ids through the recursion and added to the step a condition like NOT c.id = ANY(path). It worked, but it was verbose and easy to break when copied around. CYCLE says the same thing in one line; if you spot the old manual variant, now you know what it does.
• Deep recursion costs memory and time: the intermediate result lives in full, and on a large or poorly branching graph the query can eat a noticeable chunk of resources. On such data, in production you set a depth limit (a condition on depth in the recursive step) so the query is guaranteed to finish even if an anomaly hides in the graph.
• Trees that are read often and in bulk — catalogue navigation, comment threads, org charts — are usually denormalised in production: a materialised path is kept alongside, an ltree type is used, a closure table is built. Then "give me the whole subtree" turns into an ordinary indexed SELECT with no recursion every time. Recursive traversal is good for one-off exports and admin queries, but as a hot path under load it almost always loses to a precomputed structure.
• Remember the frame: this lesson is about the expressiveness of SQL — that a tree and a graph fit into a single query — not an invitation to move traversal business logic into the database where it belongs in code.

What to take away

A recursive CTE is an anchor plus a recursive step, glued by UNION ALL: the anchor gives the start (the tree's roots), the step attaches the children of already found nodes and repeats while there is anything to add. At each level we accumulate context — depth and path — and it is this accumulation that turns a flat table with parent_id into a tree with indentation and full paths. Deterministic ordering comes from sorting by an array of ids rather than by a name string: arrays compare element by element and don't depend on the database collation, so the pre-order is stable on any installation.

Loop protection lives in the SQL-standard CYCLE id SET is_cycle USING path clause: on a repeated id it raises a flag and cuts the recursion on that branch, so traversal of a cyclic graph finishes on its own rather than hanging up to the server limit. And the escape hatch here is no whim: sqlc does not see the virtual is_cycle/path columns and fails on static analysis — a lesson about the feature dictates the tool.

We've learned to descend into a tree and a graph in depth. Next, in 08-05, we turn the axis ninety degrees: LATERAL lets us run a separate subquery on the right for each row on the left — "for each shop give its three latest orders" — and that is no longer about going deep, but about a correlated join going wide.
